Turning an Evanston garage into an ADU — what happens to the door

Evanston is unusually permissive about accessory dwelling units, and a lot of the conversations we have now start with "we're converting the garage." Almost nobody has thought about the door yet. It is the single largest opening in the building, and what you do with it decides how the finished space performs.

This article covers three scenarios — the door comes out, the door stays and starts working for a living, or the door stays and somebody's bedroom ends up on top of it — and what each one actually needs. The rules first, briefly, because they shape all three.

What Evanston allows

Evanston legalised accessory dwelling units in September 2020 and later opened coach houses to any residentially-zoned lot. Per the City's 2026 ADU Guidebook and the City's accessory dwelling unit pages:

• Garage conversions are permitted. You must maintain parking elsewhere on the property, and the unit needs at least one code-compliant egress door.
• Above-garage units are permitted as Garage-Attached ADUs — one or two stories, adjacent to or on top of the existing garage.
• Size: detached and garage-attached ADUs are capped at under 1,000 square feet of livable space. For the garage-attached type, the garage area itself is not counted.
• Height: up to 28 feet for sloped roofs, 20 feet for flat and mansard.
• Setbacks: accessory-structure setbacks apply — a 3-foot rear yard minimum in most districts.
• Parking: no additional parking is required, but existing spaces must be maintained or replaced.
• In a historic district, a Certificate of Appropriateness from the Preservation Commission is required, and the ADU has to fit the context and architectural style of the house and the neighbourhood.

Note the last rule in the list, because it is the one that reaches the door. A garage door is the most visible exterior feature of the structure from the alley. In a designated district, what happens to it is not purely a functional decision.

Scenario one: the door comes out

Full conversion. The garage becomes living space, the vehicle parks somewhere else on the lot, and the fourteen-foot hole in the wall has to become a wall.

Structurally this is straightforward and it is a carpenter's job, not ours: the header stays, the opening gets framed down, insulated, sheathed and finished, and usually a window or a door goes into the new wall to bring light into what was a windowless box. The operator, track, springs and cables all come out.

Two things people underestimate.

The elevation changes visibly, and mostly it changes from the alley. A block of Evanston garages reads as a rhythm of doors. Take one out and infill it with siding and a window and the building announces what it now is. That is fine in most of the city. In southeast Evanston inside the Lakeshore district, or along Ridge, or in Northeast Evanston, it is a change to an exterior visible from a public way — which is precisely the trigger language in the Certificate of Appropriateness requirement.

Keeping the door as a facade element is a real option. We have seen it done well: the opening is framed and insulated behind, and the door leaf is fixed in place as a non-operating panel on the outside, or the panel profile is reproduced in the new wall. You keep the alley elevation intact and the neighbours barely notice. It costs more than plain infill and it buys you nothing functionally — but on a designated property, or on a block where the garages are part of the character, it can be the difference between an easy approval and a difficult one. If the existing door is sound and only one section is damaged, replacing that section before you fix it in place is cheaper than sourcing a whole door to look at.

Talk to whoever is handling your permit about which route the City expects. Do not fix a door in place and then find out it needed to come out, or the reverse.

Scenario two: the door stays, and starts doing real work

This is the most common version we see, and the most misunderstood. The garage becomes a studio, a workshop, a gym, a home office, a flexible room that still opens to the alley on a good day in June. It is conditioned, or at least heated when it is in use.

The moment you heat that space, the door stops being a barrier and becomes part of the thermal envelope. It is also the worst-performing part of it, because it is a large, thin, moving assembly with a gap around every edge.

What matters, in order of how much difference it makes:

• Sandwich construction, not a foam board taped to a single-skin door. A sandwich door is steel skin, insulation, steel skin, bonded as one panel. It insulates, and just as importantly it is rigid — a stiff door seals better against its weatherstripping and stays flat instead of bowing.
• Perimeter weatherstripping on both jambs and the header. On most old Evanston garages this is a strip of nailed-on wood with a flap that perished a decade ago. Replacing it is cheap and it is usually the single biggest measurable improvement.
• A bottom seal that actually seals. This is where conversions fail. The astragal has to bridge whatever the slab is doing, and an eighty-year-old garage slab is rarely flat. If there is daylight under the closed door at one corner, a standard bulb seal will not fix it — you want a deeper T-section or bulb profile with enough compression to take up the variation, and sometimes the honest answer is that the slab edge needs attention first.
• Thermal bridging through track and hardware. The vertical track, the jamb brackets, and the steel frame conduct heat straight through the wall assembly. You cannot eliminate it, but you can stop pretending an R-value printed on a panel describes the whole opening.

The Department of Energy's insulation guidance is the sane starting point for how the whole envelope fits together. The short version for this scenario: a good insulated door in a leaky uninsulated building is money spent on the wrong component. Insulate the walls and the ceiling, seal the perimeter, and then the door upgrade returns something.

Scenario three: above-garage ADU, and the door is under a bedroom

The garage stays a garage. Someone builds one or two stories on top of it, and now the door is a machine operating directly beneath a floor that people sleep on.

This changes the specification more than anything else in this article. A door and opener combination that was perfectly acceptable when the garage was a detached box at the end of the lot becomes unlivable when the ceiling above it is a bedroom.

Get the opener specification decided during design, not after. Where the operator lives affects framing, where power goes, and whether you have headroom for a rail at all.

When an insulated door is worth it, and when it is not

We talk people out of insulated doors regularly, so this is worth stating plainly.

An unheated detached garage gains very little thermally from an insulated door. The building around it leaks — uninsulated stud walls, an open rafter ceiling, gaps at the plate line, a service door with no weatherstripping. Upgrading one component of a leaky enclosure changes the interior temperature by a few degrees at best. What an insulated door does buy you there is rigidity and dent resistance, which genuinely matters on an alley where the door gets bumped.

A conditioned space, or one directly under conditioned space, is a different calculation entirely. Now the door is a wall in a heated building, and every square foot of it is losing heat all winter.

Evanston's winter makes that case better than most. Using NOAA's 1991–2020 climate normals for the nearest official station: 121 days a year with a low at or below freezing, 6.5 days at or below 0°F, and a January average high of 31.6°F. That is four months where the temperature difference across that door is thirty or forty degrees, day and night. An uninsulated single-skin door in that position is a hole in the wall with a curtain over it.

The three-foot problem

One practical constraint that catches ADU projects on Evanston lots.

Accessory-structure setbacks allow a garage as close as 3 feet from the rear property line in most districts. Plenty of Evanston garages are built right at that limit, with the door facing an alley. Which means the working space outside the door is a yard of grass and then public right of way.

That affects the build in ways worth planning for:

• Scaffolding for the storey above has to go somewhere, and on the alley side there is no somewhere
• A door that opens into three feet of clearance takes damage from vehicles, bins and snow piles at the bottom section
• Snow cannot be pushed into the alley — city rules — so it accumulates against the door and freezes to the bottom seal
• Service access for anything on the exterior is from the alley, and on the more than 300 unpaved alleys in this city that is a seasonal question

If you are already opening the building up, that is the moment to deal with drainage and the slab edge at the threshold. It is far cheaper while the contractors are there than as a separate call two winters later. We covered the whole failure sequence in what an Evanston alley does to your garage door.

Getting the sequence right

The mistake we see most is the door being treated as a finishing item. It is not. It sets headroom, it sets where the operator goes, it sets how the structure above is framed, and on a designated property it may need approving before anything else happens.

Decide early: door out, door working, or door under a bedroom. Then specify against that decision. A conversion in west Evanston where the garage becomes a workshop needs a different product from a garage-attached ADU in north Evanston where the door has to be silent at six in the morning, and both are different from a full conversion in south Evanston where the door leaves the building.

We are happy to come and look at the existing garage before the drawings are finished — headroom, backroom, the state of the header, whether the opening is square, whether the existing door is worth keeping. That is a more useful hour than any of the three scenarios above going wrong at the trim stage. Call (224) 505-2236 and say it is an ADU project, and we will bring a tape and a level rather than a van full of parts. If the outcome is a new residential door and a proper installation, good. If the outcome is that your existing door is fine and you should spend the money on wall insulation, we will tell you that instead.
